6.3.8 BITS — BIT SET
BITS dst.b
Operation: dst(b)  1
The BITS instruction sets the specified bit within the destination without affecting any other bits in
the destination.
Flags: No flags are affected.
Format:
Bytes Cycles Opcode
(Hex)
Addr Mode
dst
opc dst | b | 1 2 4 77 rb
NOTE: In the second byte of instruction format, the destination address is four bits, the bit address ‘b’ is three bits,
and the LSB address value is one bit in length.
Example: Given R1 = 07H:
BITS R1.3  R1 = 0FH
If the value of working register R1 is 07H (00000111B), the statement “BITS R1.3” sets bit three
of the destination register R1 to “1”, leaving the value 0FH (00001111B).
