Samsung S3F84B8 - Figure 10-2 Oscillation Stabilization Time on RESET

To Next Page

To Previous Page

S3F84B8_UM_REV 1.00 10 BASIC TIMER

10-4

Oscillation Stabilization Time

Normal Operating mode

0.8

VDD

tWAIT = (4096x128)/fOSC

Basic timer increment and

CPU operations are IDLE mode

10000B

00000B

Reset Release Voltage

NOTE: Duration of the oscillator stabilization wait time, tWAIT, when it is released by a

Power-on-reset is 4096 x 128/fOSC.

tRST RC (R and C are value of external power on reset)

VDD

nRESET

Internal

Reset

Release

Oscillator

(XOUT)

BTCNT

clock

BTCNT

value

Oscillator Stabilization Time

trst ~ RC

0.8 VDD

Figure 10-2 Oscillation Stabilization Time on RESET
