S3F84B8_UM_REV 1.00 6 INSTRUCTION SET
6-15
6.3.3 AND — LOGICAL AND
AND dst,src
Operation: dst dst AND src
The source operand is logically ANDed with the destination operand. The result is stored in the
destination. If the corresponding bits in two operands are both logic ones, AND operation results
in a “1” bit being stored in Z bit of FLAG; otherwise a “0” bit value is stored. The contents of the
source remain unaffected.
Flags: C: Unaffected.
Z: Set if the result is “0”; cleared otherwise.
S: Set if the result bit 7 is set; cleared otherwise.
V: Always cleared to “0”.
D: Unaffected.
H: Unaffected.
Format:
Bytes Cycles Opcode
(Hex)
Addr Mode
dst src
opc dst | src 2 4 52 r r
6 53 r lr
opc src dst 3 6 54 R R
6 55 R IR
opc dst src 3 6 56 R IM
Examples: Given R1 = 12H, R2 = 03H, register 01H = 21H, register 02H = 03H, and register 03H = 0AH:
AND R1,R2 R1 = 02H, R2 = 03H
AND R1,@R2 R1 = 02H, R2 = 03H
AND 01H,02H Register 01H = 01H, register 02H = 03H
AND 01H,@02H Register 01H = 00H, register 02H = 03H
AND 01H,#25H Register 01H = 21H
In the first example, destination working register R1 contains the value 12H and source working
register R2 contains the value 03H. The statement “AND R1,R2” logically ANDs the source
operand value 03H with the destination operand value 12H, leaving the value 02H in register R1.
