S3F84B8_UM_REV 1.00 6 INSTRUCTION SET
6-52
6.3.39 LDC/LDE — LOAD MEMORY (CONTINUED)
LDC/LDE
Examples: Given R0 = 11H, R1 = 34H, R2 = 01H, R3 = 04H; Program memory locations
0103H = 4FH, 0104H = 1A, 0105H = 6DH, and 1104H = 88H; External data memory locations
0103H = 5FH, 0104H = 2AH, 0105H = 7DH, and 1104H = 98H:
LDC R0,@RR2 ; R0 contents of program memory location 0104H
; R0 = 1AH, R2 = 01H, R3 = 04H
LDE R0,@RR2 ; R0 contents of external data memory location 0104H
; R0 = 2AH, R2 = 01H, R3 = 04H
LDC
(NOTE)
@RR2,R0 ; 11H (contents of R0) is loaded into program memory
; location 0104H (RR2),
; working registers R0, R2, R3 no change
LDE @RR2,R0 ; 11H (contents of R0) is loaded into external data memory
; location 0104H (RR2),
; working registers R0, R2, R3 no change
LDC R0,#01H[RR2] ; R0 contents of program memory location 0105H
; (01H + RR2),
; R0 = 6DH, R2 = 01H, R3 = 04H
LDE R0,#01H[RR2] ; R0 contents of external data memory location 0105H
; (01H + RR2), R0 = 7DH, R2 = 01H, R3 = 04H
LDC
(note)
#01H[RR2],R0 ; 11H (contents of R0) is loaded into program memory location
; 0105H (01H + 0104H)
LDE #01H[RR2],R0 ; 11H (contents of R0) is loaded into external data memory
; location 0105H (01H + 0104H)
LDC R0,#1000H[RR2] ; R0 contents of program memory location 1104H
; (1000H + 0104H), R0 = 88H, R2 = 01H, R3 = 04H
LDE R0,#1000H[RR2] ; R0 contents of external data memory location 1104H
; (1000H + 0104H), R0 = 98H, R2 = 01H, R3 = 04H
LDC R0,1104H ; R0 contents of program memory location 1104H,
; R0 = 88H
LDE R0,1104H ; R0 contents of external data memory location 1104H,
; R0 = 98H
LDC
(NOTE)
1105H,R0 ; 11H (contents of R0) is loaded into program memory location
; 1105H, (1105H) 11H
LDE 1105H,R0 ; 11H (contents of R0) is loaded into external data memory
; location 1105H, (1105H) 11H
NOTE: These instructions are not supported by masked ROM type devices.
