S3F84B8_UM_REV 1.00 6 INSTRUCTION SET
6-83
6.3.71 TM — TEST UNDER MASK
TM dst,src
Operation: dst AND src
This instruction tests selected bits in destination operand for logic zero value. The bits to be
tested are specified by setting a “1” bit in the corresponding position of source operand (mask),
which is ANDed with destination operand. The zero (Z) flag can then be checked to determine the
result. The destination and source operands remain unaffected.
Flags: C: Unaffected.
Z: Set if the result is “0”; cleared otherwise.
S: Set if the result bit 7 is set; cleared otherwise.
V: Always reset to “0”.
D: Unaffected.
H: Unaffected.
Format:
Bytes Cycles Opcode
(Hex)
Addr Mode
dst src
opc dst | src 2 4 72 r r
6 73 r lr
opc src dst 3 6 74 R R
6 75 R IR
opc dst src 3 6 76 R IM
Examples: Given R0 = 0C7H, R1 = 02H, R2 = 18H, register 00H = 2BH, register 01H = 02H, and register
02H = 23H:
TM R0,R1 R0 = 0C7H, R1 = 02H, Z = “0”
TM R0,@R1 R0 = 0C7H, R1 = 02H, register 02H = 23H, Z = “0”
TM 00H,01H Register 00H = 2BH, register 01H = 02H, Z = “0”
TM 00H,@01H Register 00H = 2BH, register 01H = 02H,
register 02H = 23H, Z = “0”
TM 00H,#54H Register 00H = 2BH, Z = “1”
In the first example, if working register R0 contains the value 0C7H (11000111B) and register R1
contains the value 02H (00000010B), the statement “TM R0,R1” tests bit one in the destination
register for a “0” value. Since the mask value does not match the test bit, the Z flag is cleared to
logic zero and can be tested to determine the result of TM operation.
