12.2 TWO 8-BIT TIMERS MODE (TIMER C AND D)
12.2.1 OVERVIEW OF TWO 8-BIT TIMERS MODE (TIMER C AND D)
Timers C and D are 8-bit general-purpose timers. Timer C works in the interval timer mode, while Timer D works
in the interval timer and PWM modes by using the appropriate TCCON and TDCON setting, respectively.
Timers C and D have the following functional components:
 Prescaler for Timer C clock frequency programmable from fx to fx/4096
Prescaler for Timer D clock frequency programmable from fx to fx/4096
 8-bit counter (TCCNT and TDCNT), 8-bit comparator, and 8-bit reference data register (TCDATA and
TDDATA)
 Timer C match interrupt generation
 Timer C control register, TCCON (E5H, bank1, read/write)
 Timer D has an I/O pin for match and PWM output (P2.0, TDOUT)
 Timer D overflow interrupt generation
 Timer D match interrupt generation
 Timer D control register, TDCON (E9H, bank1, read/write)
12.2.2 TIMER C AND D CONTROL REGISTER (TCCON, TDCON)
You can use the Timers C and D control registers, TCCON and TDCON, for the following purposes:
 Enable the Timer C (interval timer mode) and Timer D operation (interval timer mode and PWM mode).
 Select the Timer C clock source.
 Clear the Timers C and D counter, TCCNT and TDCNT.
 Enable the Timers C and D interrupt.
 Clear the Timers C and D interrupt pending conditions.
You can use Timer C prescaler register, TCPS, for the following purposes:
 Select the clock source. Comparator 0’s output can be configured to the clock source of Timer C.
 Select the clock prescaler.
 You can use Timer D prescaler register, TDPS, for the following purpose:
 Program clock prescaler
