16.2.5 PWM CMP LINKAGE CONTROL REGISTER (PWMCCON)
The control register for linkage of CMP and PWM module, PWMCCON, is located at register address F0H, Set 1,
Bank 0.
Bit settings in the PWMCCON register control the linkage configuration of PWM CMP0, PWM CMP1, PWM
CMP2, and PWM CMP3.
A reset clears all the PWMCCON bits to logic zero, disabling the entire linkage.
LSBMSB
PWM Control Registers (PWMCCON)
F0H, Set 1, Bank 0, Reset=00H, R/W
CMP1 PWM trigger mode :
X0 = disable linkage
01 = Soft lock
11 = hard lock
CMP0 PWM trigger mode :
X0 = Disable linkage
01 = Normal trigger
11 = Delay trigger
.7 .6 .5 .4 .3 .2 .1 .0
CMP2 PWM trigger mode :
X0 = disable linkage
01 = Soft lock
11 = hard lock
CMP3 PWM trigger mode :
X0 = disable linkage
01 = Soft lock
11 = hard lock
Figure 16-2 PWM CMP Linkage Control Register (PWMCCON)
LSBMSB
Anti-mis-trigger Data Registers (AMTDATA)
F6H, Set 1, Bank 0, Reset=00H, R/W
.7 .6 .5 .4 .3 .2 .1 .0
Anti-mis-trigger time = (AMTDATA x4)/fpwmclk + T
ST
0<T
ST
(setting time ) < 4/fpwmclk
NOTE:
Figure 16-3 Anti-mis-trigger Data Register (AMTDATA)
LSBMSB
PWM Delay trigger Registers (PWMDL)
F5H, Set 1, Bank 0, Reset=00H, R/W
----.3.2.1.0
Delay Time = (PWMDL+1)x 4/fpwmclk + T
ST
0<T
ST
(Setting time ) < 4/fpwmclk NOTE:
Figure 16-4 Delay trigger Data Register (PWMDL)
