S3F84B8_UM_REV 1.00 3 ADDRESSING MODES

3-14

3.14 IMMEDIATE MODE (IM)

In Immediate (IM) addressing mode, the operand value used in instruction is the value supplied in operand field

itself. The operand can be one byte or one word in length, depending on the instruction used. Immediate

addressing mode is useful for loading constant values into registers.

(The Operand value is in the instruction)

OPCODE

Sample Instruction:

LD R0,#0AAH

Program Memory

OPERAND

Figure 3-14 Immediate Addressing
