Table 21-8 OP AMP Electrical Characteristics
(T
A
= –40C to + 85C, V
DD
= 2.0V to 5.5V)
Parameter Symbol Conditions Minimum Typical Maximum Unit
V
DD
= 2.0V
– 10
30
(1)
mV
Input offset voltage
|V
io
|
V
DD
= 5.5V
– 10
30
(1)
mV
Input common-mode
voltage range
(2)
V
cm
GND –
V
DD
–0.1
V
Output voltage
V
out
GND+0.1 –
V
DD
–0.1
V
NOTE:
1. For the hardware and software calibration methods, refer to the Application Note.
2. The input signal voltage should not go below –0.3V.
Table 21-9 Comparator Electrical Characteristics
(T
A
= –40C to + 85C, V
DD
= 2.0V to 5.5V)
Parameter Symbol Conditions Minimum Typical Maximum Unit
V
DD
= 2V
– 10 20 mV
CMP0
input offset voltage
(1)
|V
io
|
V
DD
= 5.5V
– 10 20 mV
V
DD
= 2V
– 15 30 mV
CMP1/2/3
input offset voltage
(1), (2)
|V
io
|
V
DD
= 5.5V
– 15 30 mV
CMP0
input common mode
voltage range
V
cm
GND – VDD–0.1 V
NOTE:
1. These parameters are characterized only, but not tested.
2. Parameter includes the tolerance level of internal voltage reference.
