S3F84B8_UM_REV 1.00 1 OVERVIEW OF S3F84B8 MICROCONTROLLER
1-9
1.1.6 PIN CIRCUITS
Figure 1-3
shows the pin circuit type 1 in S3F84B8.
P-Channel
N-Channel
VDD
Out
Output
Disable
Data
Figure 1-3 Pin Circuit Type 1
Figure 1-4
shows the pin circuit type 2 in S3F84B8.
P-Channel
N-Channel
VDD
Out
Output
Disable
Data
Open drain enable
Figure 1-4 Pin Circuit Type 2
