Samsung S3F84B8 - 20-SOP-375 Package Dimensions

To Previous Page

S3F84B8_UM_REV 1.00 23 MECHANICAL DATA

23-2

NOTE:

Dimensions are in millimeters.

20-SOP-375

10.300.30

#11#20

#10

13.14 MAX

12.74





0.20

(0.66)

0-8

0.203

+ 0.10

- 0.05

9.53

7.50

0.20

0.850.20

0.05 MIN 2.300.10

2.50 MAX

0.40

0.10 MAX

+ 0.10

- 0.05

1.27

Figure 23-2 20-SOP-375 Package Dimensions
