10-bit IH PWM

 10-bit IH specific PWM 1-channel

 Cooperate with CMPs

 Anti-mis-trigger function

 Delay trigger function

Comparators

 4 integrated comparators

A/D Converter

 8 analog input pins (MAX)

 10-bit conversion resolution

OP Amplifier

 1 integrated OP Amplifier

Timer/Counters

 1 basic timer (8-bit) for watchdog function

 1 timer (8-bit) TimerA

 Interval mode

 Capture mode

 8-bit PWM mode

 1 timer/counter (16-bit) Timer0

 Configurable to 2 timer/counters (8-bit)

 Interval mode

 CMP0 event counter mode

 6-/7-/8-bit PWM mode

BUZ

 1 programmable Buzzer

Oscillation Frequency

 1MHz to 10MHz external crystal oscillator

 Typical 8MHz external RC oscillator

 Internal RC: 8MHz (Typical), 0.5MHz (Typical)

 Maximum 10MHz CPU clock
