Samsung S3F84B8 - Page 256

To Next Page

To Previous Page

S3F84B8_UM_REV 1.00 13 A/D CONVERTER

13-4

50 ADC Clock

ADCON.0 1

. . .

40 Clock

Value

Valid

Data

Set up

time

10 clock

ADDATAH (8-Bit) + ADDATAL (2-Bit)

9 8 7 6 5 4 3 2 1 0

Conversion

Start

EOC

ADDATA

Figure 13-4 A/D Converter Timing Diagram
