S3F84B8_UM_REV 1.00 14 COMPARATOR

14-3

14.1.1.1.2 Block Diagram of Comparator 0

C0PLR (CMP0CON.4)

C0EN (CMP0CON.3)

CMP0CON.0

PWM

CMP0_N

CMP0_P

CMP0

SET

CLR

Interrupt

Fosc

CMP0CON.1

INT Enable (CMP0CON.2)

CMPINT.1-.0

INT

CTRL

NOTE:

1. Polarity selection bit (CMP0CON.4) will not affect interrupt generation logic.

2. PWM trigger signal is falling edge active only.

Figure 14-3 Block Diagram of Comparator 0
