S3F84B8_UM_REV 1.00 16 10-BIT IH-PWM

16-8

Hard Lock trigger

PWM OUTPUT

PWM LOCK

IGBT ON

IGBT OFF

NOTE: Because CMP1/2/3 is asynchronous, lock action happens immediately without any setting time .

Figure 16-8 Example of the Cooperation of PWM and Comparator 1/2/3_ Hard Lock

CMP0 OUTPUT

(SYN CMP)

PWM OUTPUT

PWMPDATA

IGBT ON

IGBT OFF

Soft Lock Trigger

IGBT ON

IGBT OFF

NOTE: Because CMP1/2/3 is asynchronous,lock action happens immediately without any setting time.

Figure 16-9 Example of the Cooperation of PWM and Comparator 1/2/3_Soft Lock
