S3F84B8_UM_REV 1.00 19 EMBEDDED FLASH MEMORY INTERFACE

19-7

Example 19-1 Sector Erase

Case 1. Erase one sector



ERASE_ONESECTOR:

LD FMUSR,#0A5H ; Enables user program mode

LD FMSECH,#04H ; Set sector address 0400H, sector 8,

LD FMSECL,#00H ; among sector 0–32

LD FMCON,#10100001B ; Select erase mode enable and Start sector erase

ERASE_STOP: LD FMUSR,#00H ; Disables user program mode
