SATO HR2 Series User Manual

Section 8: Appendix
Page 8-6
HR2 Series Operator Manual
8.4 BASE REFERENCE POINT ADJUSTMENT (Cont’d)
8.4.2 Adjustment of Stop Position When Using Dispenser/ Tear-off
Label stop position for optional devices is adjustable within the range of +3.75mm to -3.75mm (+0.15" to -
0.15") due to the above settings on LCD screen
Notes
• The above dispense position will be the stop position when the GAP sensor is selected.
• Tear-off position is adjustable in the same manner.
Adjustments for Dispenser / Tear-off
Stop position for Dispense/
Tear - off mode
Setup on LCD
Adjustment mode: OFFSET
/ Test Print mode: OFFSET
POSITION
+3.75mm to -3.75mm
(+0.15" to -0.15")
-3.75mm (-0.15")
Label feed direction
Base reference
point for printing
(Print head)
Adjustment for
“+” value
No
Adjustment
Adjustment for
“-” value
Dispenser
+3.75mm (+0.15")
15.21mm
(0.6")
