Section 2: Installation
HR2 Series Operator Manual Page 2-7
2.3 LOADING MEDIA (cont’d)
2.3.2 When operating in continuous mode for the first time
1.
Slide down the Dispenser unit open button to open the dispenser unit.
2. Remove the dispenser roller mounted in the dispenser unit.
While pushing the dispenser roller downwards, pull towards your side to remove it.
Notes:
• Keep the dispenser roller in a safe place.
• Mount with the reversed procedures when you need to issue labels in dispense mode.
3. Close the dispenser unit.
2.3.3 To load the media when operating in continuous mode
1.
Lift up the Top cover while holding down the OPEN button.
2. Load the media. (Refer to steps 2~5 of Section 2.3.1 To load the label when using the dispenser)
3. Close the top cover.
