SATO HR2 Series User Manual

Section 8: Appendix
Page 8-10
HR2 Series Operator Manual
8.6 RIBBON END
The printer will indicate the ribbon end error after the ribbon slit sensor detection of the error and 5mm (0.2")
feeding.
Ribbon (Rewinding)
Print head
Ribbon (Unwinding)
Spring
Slit sensor
Print direction
Print head
Spring
Slit sensor
Print direction
Back sealing tape
Ribbon (Unwinding)
Ribbon (Rewinding)
