SATO HR2 Series User Manual

Section 3: Operation and Configuration
HR2 Series Operator Manual Page 3-49
3.13 TEST PRINT MODE (Cont’d)
2)Second page --
3)Third page --
Item name (Print) Description
Reflective Sensor
Low [Lo<0.4] x.x(V)
High[0.9<Hi-Lo] x.x(V)
Slice Level Auto
Printing this information when reflective sensor (I-Mark) is selected.
If “Low” is not [Low < 0.4], “Low” will be indicated in reverse colors.
If “High” is not [0.9 < (High-Low)], “High” will be indicated in reverse colors.
Transmissive Sensor GAPx
Low [0.1<Lo<0.6] x.x(V)
High[0.9<Hi-Lo] x.x(V)
Slice Level Auto
Printing this information when transmissive sensor (GAP) is selected.
Indicates GAP sensor number in use by “x” in "GAP(x)".
If “Low” is not [0.6 < Low < 1.0], “Low” will be indicated in reverse color.
If “High” is [0.9 < (High-Low)], “High” will be indicated in reverse colors.
Pitch(LCD) Printing the pitch position set through LCD screen.
±3.75(mm)
Offset(LCD) Printing the offset position set through LCD screen.
±3.75(mm)
Darkness(LCD) Printing the print darkness set through LCD screen
00~99
EXT Signal TYPE1, TYPE2, TYPE3 or TYPE4
EXT Dispenser Enabled/Disabled
EXT Reprint Enabled/Disabled
Label Size Printing the label size set in the printer.
(P)xxxx x (W)xxxx(dot)
DSW ON/OFF
Item name (Print) Description
Keypad Enabled/Disabled
DATA PORT LAN / RS-232C / USB
SUB PORT None / RS-232C / USB / LAN
Interface display
LAN
Protocol STATUS3
STATUS4 (ENQ)
STATUS4 (CYC)
STATUS5
RS-232C
Protocol READY/BUSY
XON/XOFF
STATUS2
STATUS3
STATUS4
STATUS5
USB
Protocol STATUS4
STATUS5
