Date Code 20081022 Instruction Manual SEL-787 Relay
Protection and Logic Functions
Logic Settings (SET L Command)
The pickup times of 0 for the SV03PU and SV04PU settings shown above
provide an immediate Close and Trip actions from front-panel pushbuttons.
For a delayed Close, set SV03PU to the desired delay. Similarly, set SV04PU
for a delayed Trip action. See Table 8.4 for more detail.
Counter Variables
SELOGIC counters are up- or down-counting elements, updated every
processing interval.
Each counter element consists of one count setting, four control inputs, two
digital outputs, and one analog output. Figure 4.51 shows Counter 01, the first
of 32 counters available in the device.
Figure 4.51 Counter 01
Digital output SC01QD asserts when the counter is at position zero, and
Digital output SC01QU asserts when the counter reaches the programmable
count value. Use the reset input (SC01R) to force the count to zero, and the
analog output (SCnn) with analog comparison operators. Table 4.30 describes
the counter inputs and outputs, and Table 4.31 shows the order of precedence
of the control inputs.
SV TIMER DROPOUT 0.00–3000.00 sec SV03DO := 0.00
SV INPUT SEL
OGIC SV03 := LT03
SV TIMER PICKUP 0.00–3000.00 sec SV04PU := 0.00
SV TIMER DROPOUT 0.00–3000.00 sec SV04DO := 0.00
SV INPUT SEL
OGIC SV04 := LT04
SV TIMER PICKUP 0.00–3000.00 sec SV05PU := 0.25
SV TIMER DROPOUT 0.00–3000.00 sec SV05DO := 0.25
SV INPUT SEL
OGIC SV05 := (PB01 OR PB02 OR
LT03 OR LT04) AND NOT
SV05T
Ta b le 4. 29 SE L
OGIC Variable Settings (Sheet 2 of 2)
Setting Prompt Setting Range Default Settings
Table 4.30 Counter Input/Output Description (Sheet 1 of 2)
Name Type Description
SCnnLD Active High Input Load counter with the preset value to assert the output
(SCnQU) (follows SEL
OGIC setting).
SCnnPV Input Value This Preset Value is loaded when SCnLD pulsed. This
Preset Value is the number of counts before the output
(SCnQU) asserts (follows SEL
OGIC setting).
SCnnCU Rising-Edge Input Count Up increments the counter (follows SEL
OGIC
setting).
NOTE: These counter elements
conform to the standard counter
function block #3 in IEC 1131-3 First
Edition 1993-03 International
Standard for Programmable
controllers—Part 3: Programming
languages.
NOTE: For device configurations that
include voltage cards, the SEL-787
tracks the frequency. When tracking
the frequency, the processing interval
varies with the frequency.
NOTE: If setting SCnnCD is set to NA,
the entire counter nn is disabled).
SC01PV
SC01R
SC01LD
SC01CU
SC01CD
Counter 01
SC01QU
SC01QD
SC01
SELOGIC
Output
