6.4
SEL-787 Relay Instruction Manual Date Code 20081022
Settings
View/Change Settings Over Communications Port
View/Change Settings Over Communications Port
Refer to Section 7: Communications for information on how to set up and
access the relay serial or Ethernet port with a personal computer and how to
use ASCII commands to communicate with the relay.
View Settings
Use the SHOW command to view relay settings. The SHOW command is
available from Access Level 1 and Access Level 2. Table 6.2 lists the SHOW
command options.
You may append a setting name to each of the commands to specify the first
setting to display (e.g., SHO 50P11P displays the relay settings starting with
setting 50P11P). The default is the first setting. The SHOW command
displays only the enabled settings.
Enter Settings
The SET command (available from Access Level 2) allows you to view or
change settings. Table 6.3 lists the SET command options.
You may append a setting name to each of the commands to specify the first
setting to display (e.g., SET 50P1P displays the relay settings starting with
setting 50P1P). The default is the first setting.
When you issue the SET command, the relay presents a list of settings one at
a time. Enter a new setting or press <Enter> to accept the existing setting.
Editing keystrokes are listed in Table 6.4.
Table 6.2 SHOW Command Options
Command Description
SHOW Show relay group settings.
SHO D Show DNP3 map settings.
SHO F Show front-panel display and LED settings.
SHO G Show global configuration settings.
SHO L Show logic settings.
SHO M Show Modbus map settings.
SHO P n Show serial port settings for Port n (n = F, 1, 2, 3, or 4).
SHO R Show Sequential Event Report (SER) and Event Report settings.
Table 6.3 SET Command Options
Command Settings Type Description
SET Relay Protection elements, timers, etc.
SET D DNP DNP3 map settings
SET F Front Panel Front-panel display and LED settings
SET G Relay Global configuration
SET L Logic General logic settings
SET M Modbus Modbus user map
SET P Port Serial port settings
SET R Reports SER and Event Report settings
NOTE: The SET command is not
available up to 90 seconds after the
relay is powered up and up to
40 seconds after a setting change. If
you issue a SET command during this
period, the relay responds with the
following message:
Command Unavailable;
Relay Configuration in
Progress, Try Again.
