SEL-787 Relay Instruction Manual Date Code 20081022
Analyzing Events
Event Reporting
This example event report displays rows of information each 1/4 cycle.
Retrieve this report with the EVE D command.
Table 9.3 gives the digital event report column definitions for the protection
and control elements and the inputs and outputs.
Table 9.3 Digital Event Report Column Definitions (Sheet 1 of 4)
Column Designation
Column
Symbols
Column Symbol Relay Word Bits (RWB)
50P11 *
t
50P11P picked up
50 P11T picked up
50P12 *
t
50P12P picked up
50P12T picked up
50P13 *
t
50P13P picked up
50P13T picked up
50P14 *
t
50P14P picked up
50P14T picked up
50G11 *
t
50G11P picked up
50G11T picked up
50G12 *
t
50G12P picked up
50G12T picked up
50Q11 *
t
50Q11P picked up
50Q11T picked up
50Q12 *
t
50Q12P picked up
50Q12T picked up
51P1 *
t
r
51P1P picked up
51P1T picked up
51P1R picked up
51G1 *
t
r
51G1P picked up
51G1T picked up
51G1R picked up
51Q1 *
t
r
51Q1P picked up
51Q1T picked up
51Q1R picked up
51P21 *
t
51P21P picked up
51P21T picked up
51P22 *
t
51P22P picked up
51P22T picked up
51P23 *
t
51P23P picked up
51P23T picked up
51P24 *
t
51P24P picked up
51P24T picked up
51G21 *
t
51G21P picked up
51G21T picked up
51G22 *
t
51G22P picked up
51G22T picked up
51Q21 *
t
51Q21P picked up
51Q21T picked up
51Q22 *
t
51Q22P picked up
51Q22T picked up
51P2 *
t
r
51P2P picked up
51P2T picked up
51P2R picked up
NOTE: Active bits will depend on the
options included in the relay.
