1.6
SEL-787 Relay Instruction Manual Date Code 20081022
Introduction and Specifications
Getting Started
Checking
Relay Status
Use the STA serial port command to view the SEL-787 operational status.
Analog channel dc offset and monitored component status are listed in the
status report depicted in Figure 1.2.
=>>STA <Enter>
SEL-787 Date: 03/20/2008 Time: 13:09:10
TRNSFRMR RELAY Time Source: Internal
Serial Num = 2008xxxxxxxxxxx
FID = SEL-787-R100-V0-Z001001-D20080319 CID = 26FF
PART NUM = 0787EX1B0X0X7585023X
SELF TESTS (W=Warn)
FPGA GPSB HMI RAM ROM CR_RAM NON_VOL CLOCK RTD CID_FILE +3.3V
OK OK OK OK OK OK OK OK OK OK 3.28
+5.0V +2.5V +3.75V -1.25V -5.0V BATT
4.97 2.48 3.75 -1.24 -5.05 3.28
Option Cards
CARD_C CARD_D CARD_E CURRENT
OK OK OK OK
Offsets
IAW1 IBW1 ICW1 IAW2 IBW2 ICW2 IN VA VB VC
OK OK OK OK OK OK OK OK OK OK
Relay Enabled
=>>
Figure 1.2 STA Command Response—No DeviceNet Communications Card or
With EIA-232/EIA-485 Communications Card
If a communications card with the DeviceNet protocol is present, the status
report depicted in Figure 1.3 applies. If a communications card with Modbus
RTU protocol is present, the status report depicted in Figure 1.2 applies.
=>STA <Enter>
SEL-787 Date: 03/20/2008 Time: 15:15:40
TRNSFRMR RELAY Time Source: Internal
Serial Num = 2008xxxxxxxxxxx
FID = SEL-787-R100-V0-Z001001-D20080319 CID = 8509
PART NUM = 0787EX1BA30X7585023X
SELF TESTS (W=Warn)
FPGA GPSB HMI RAM ROM CR_RAM NON_VOL CLOCK RTD CID_FILE +3.3V
OK OK OK OK OK OK OK OK OK OK 3.28
+5.0V +2.5V +3.75V -1.25V -5.0V BATT
4.97 2.48 3.75 -1.24 -5.25 3.26
Option Cards
CARD_C CARD_D CARD_E CURRENT
OK OK OK OK
DeviceNet
DN_MAC_ID ASA DN_RATE DN_STATUS
10 1a14 edefh 500kbps 0001 1010
Offsets
IAW1 IBW1 ICW1 IAW2 IBW2 ICW2 IN VA VB VC
OK OK OK OK OK OK OK OK OK OK
Relay Enabled
=>
Figure 1.3 STA Command Response—With DeviceNet Communications Card
Table 7.47 provides the definition of each status report designator. The
beginning of the status report printout (see Figure 1.2) contains the relay
firmware identification string (FID) and checksum string (CID). These strings
uniquely identify the relay and the version of the operating firmware.
