Settings Database Management and Drivers
Terminal Logging
To create a file that contains all terminal communications with the relay, select
Terminal Logging in the Log menu, and specify a file at the prompt.
ACSELERATOR QuickSet records communications events and errors in this
file. Click Log > Connect Log to view the log. Clear the log by selecting
Log > Clear Connection Log.
Drivers and Part
Number
After clicking Tools > Terminal, access the relay at Access Level 1. Issue the
ID command to receive an identification report, as shown in Figure 3.5.
=>ID <Enter>
"FID=SEL-787-R100-V0-Z001001-D20080407","0947"
"BFID=BOOTLDR-R303-V0-Z000000-D20060612","0949"
"CID=26FF","0271"
"DEVID=SEL-787","03D0"
"DEVCODE=71","030F"
"PARTNO=0787EX1B0X0X7585023X","073D"
"CONFIG=11111201","03EB"
"iedName =TEMPLATE","0380"
"type =SEL-787","028F"
"configVersion =ICD-787-R100-V0-Z001001-D20080326","0629"
=>
Figure 3.5 Device Response to the ID Command
Locate and record the Z number (Z001001) in the FID string. The first portion
of the Z number (Z001…) determines the
ACSELERATOR QuickSet relay
settings driver version when you are creating or editing relay settings files.
The use of the Device Editor driver version will be discussed in more detail
later in this section—see Settings Editor (Editor Mode) on page 3.8. Compare
the part number (
PARTNO=0787XXXXXXXXXXXXXXXX) with the Model Option
Table (MOT) to ensure the correct relay configuration.
Settings Database Management and Drivers
ACSELERATOR QuickSet uses a database to save relay settings.
ACSELERATOR QuickSet contains sets of all settings files for each relay
specified in the Database Manager. Choose appropriate storage backup
methods and a secure location for storing database files.
Active Database
Change the active database to the one that needs to be modified by selecting
File > Active Database on the main menu bar.
Database Manager
Select File > Database Manager on the main menu bar to create new
databases and manage records within existing databases.
Settings Database
Step 1. Open the Database Manager to access the database. Click File
> Database Manager. A dialog box appears.
The default database file already configured in
ACSELERATOR
QuickSet is Relay.rdb. This database contains example settings
files for the SEL products with which you can use
ACSELERATOR QuickSet.
Step 2. Enter descriptions for the database and for each relay or relay
in the database in the Database Description and Settings
Description dialog boxes.
