Schweitzer Engineering Laboratories SEL-787 - Figure 6.1 Front-Panel Setting Entry Example

To Next Page

To Previous Page

6.3

Date Code 20081022 Instruction Manual SEL-787 Relay

Settings

View/Change Settings With Front Panel

Figure 6.1 Front-Panel Setting Entry Example

Main Menu

Meter

Events

Targets

Control

Set/Show

Status

Press to move

within the list.

Press to

return to the

previous list.

Press to select an

underlined menu item.

GROUP

Set/Show Menu

Global

Group

Port

Active Group

Date

Time

Password

1 Menu

ID Settings

Config Settings

Diff Element

•

Demand Mtr Set

Trip/Close Logic

PTR Setting

PHASE PT RATIO

PTR=00180.00

Config Menu

W1CT

WYE

PTR

180.00

•

SINGLEV

Main Page
