Schweitzer Engineering Laboratories SEL-787 - Figure 9.8 Example Sequential Events Recorder (SER) Event Report

To Next Page

To Previous Page

9.22

SEL-787 Relay Instruction Manual Date Code 20081022

Analyzing Events

Sequential Events Recorder (SER) Report

Example SER Report

The example SER report in Figure 9.8 includes records of events that occurred

before the beginning of the event summary report in Figure 9.3.

=>SER <Enter>

SEL-787 Date: 02/14/2008 Time: 13:22:53

TRNSFRMR RELAY Time Source: Internal

Serial No = 000000000000000

FID = SEL-787-X122HR-V0-Z001001-D20080212 CID = 26FF

# DATE TIME ELEMENT STATE

5 02/14/2008 13:09:57.353 87R Asserted

4 02/14/2008 13:09:57.353 TRIPXFMR Asserted

3 02/14/2008 13:09:57.615 ORED51T Asserted

2 02/14/2008 13:19:17.186 SALARM Asserted

1 02/14/2008 13:19:18.190 SALARM Deasserted

Figure 9.8 Example Sequential Events Recorder (SER) Event Report
