Schweitzer Engineering Laboratories SEL-787 - Figure D.4 Port MAP Command

D.14
SEL-787 Relay Instruction Manual Date Code 20081022
DNP3 Communications
DNP3 in the SEL-787
=>MAP DNP 1 1 <Enter>
SEL-787 Date: 02/14/2008 Time: 09:33:39
TRNSFRMR RELAY Time Source: Internal
Map 1
Transport TCP
Device IP Address 10.201.5.3
Master IP Address 10.200.0.139
Device DNP TCP and UDP Port 20000
Device DNP Address 15
Master DNP Address 0
Binary Inputs
--------------------------------------------------------------------------------
INDEX POINT LABEL EVENT CLASS SER TIMESTAMP
0 ENABLED 1 No
1 T01_LED 1 No
2 T02_LED 1 No
3 T03_LED 1 No
…
97 IN101 1 No
98 IN102 1 No
99 52A1 1 No
Binary Outputs
--------------------------------------------------------------------------------
INDEX POINT LABEL
0 RB01
1 RB02
2 RB03
…
29 RB30
30 RB31
31 RB32
Counters
--------------------------------------------------------------------------------
INDEX POINT LABEL EVENT CLASS DEADBAND
0 SC01 0 1
1 SC02 0 1
2 SC03 0 1
…
29 SC30 0 1
30 SC31 0 1
31 SC32 0 1
Analog Inputs
--------------------------------------------------------------------------------
INDEX POINT LABEL EVENT CLASS SCALE FACTOR DEADBAND
0 IAW1_MAG 2 10.0000 1000
1 IBW1_MAG 2 10.0000 1000
2 ICW1_MAG 2 10.0000 1000
3 IAW2_MAG 2 10.0000 1000
4 IBW2_MAG 2 10.0000 1000
5 ICW2_MAG 2 10.0000 1000
6 IGW1_MAG 2 10.0000 1000
7 IGW2_MAG 2 10.0000 1000
8 IN_MAG 2 10.0000 1000
9 IAVW1MAG 2 10.0000 1000
10 IAVW2MAG 2 10.0000 1000
11 3I2W1MAG 2 10.0000 1000
12 3I2W2MAG 2 10.0000 1000
13 FREQ 2 1.0000 100
14 VAB_MAG 2 10.0000 2000
15 VBC_MAG 2 10.0000 2000
16 VCA_MAG 2 10.0000 2000
17 VAVE_MAG 2 10.0000 2000
18 3V2_MAG 2 10.0000 2000
…
…
96 P 2 10.0000 100
97 Q 2 10.0000 100
98 S 2 10.0000 100
99 PF 2 10.0000 100
Analog Outputs
--------------------------------------------------------------------------------
INDEX POINT LABEL
0 GROUP
1 NOOP
Figure D.4 Port MAP Command
