Schweitzer Engineering Laboratories SEL-787 - Table F.13 Logical Device: ANN (Annunciation)

F.19
Date Code 20081022 Instruction Manual SEL-787 Relay
IEC 61850 Communications
Logical Nodes
Table F.13 shows the LN associated with annunciation elements defined as
Logical Device ANN.
Table F.13 Logical Device: ANN (Annunciation)
Logical Node Status Relay Word Bit Comment
Analog Quantities
MVGGIO12 AnIn01.mag to AnIn32.mag Math Variables (MV01–MV32)
a
SCGGIO20 AnIn01.mag–AnIn32.mag SELogic Counters (SC01–SC32)
b
AINCGGIO21 AnIn01.mag–AnIn04.mag Analog Inputs (AI301–AI304)—Slot C
c
AINDGGIO22 AnIn01.mag–AnIn04.mag Analog Inputs (AI401–AI404)—Slot D
c
AINEGGIO23 AnIn01.mag–AnIn04.mag Analog Inputs (AI501–AI504)—Slot E
c
Relay Word Bits
INAGGIO1 Ind01.stVal–Ind02.stVal Digital Inputs (IN101–IN102)—Slot A
OUTAGGIO2 Ind01.stVal–Ind03.stVal Digital Outputs (OUT101–OUT103)—Slot A
SVGGIO3 Ind01.stVal–Ind32.stVal SELogic Variables (SV01–SV32)
d
SVTGGIO4 Ind01.stVal–Ind32.stVal SELogic Variable Timers (SV01T–SV32T)
d
LTGGIO5 Ind01.stVal–Ind32.stVal Latch Bits (LT01–LT32)
e
TLEDGGIO6 Ind01.stVal–Ind08.stVal Target LEDs (ENABLED, TRIP_LED, TLED_01–TLED_06)
PBLEDGGIO7 Ind01.stVal–Ind08.stVal Pushbutton LEDs (PB1A_LED–PB4B_LED)
RMBAGGIO8 Ind01.stVal–Ind08.stVal Receive MIRRORED BITS (RMB1A–RMB8A)
TMBAGGIO9 Ind01.stVal–Ind08.stVal Transmit MIRRORED BITS (TMB1A–TMB8A)
RMBBGGIO10 Ind01.stVal–Ind08.stVal Receive MIRRORED BITS (RMB1B–RMB8B)
TMBBGGIO11 Ind01.stVal–Ind08.stVal Transmit MIRRORED BITS (TMB1B–TMB8B)
INCGGIO13 Ind01.stVal–Ind08.stVal Digital Inputs (IN301–IN308)—Slot C
c
OUTCGGIO14 Ind01.stVal–Ind04.stVal Digital Outputs (OUT301–OUT304)—Slot C
c
INDGGIO15 Ind01.stVal–Ind08.stVal Digital Inputs (IN401–IN408)—Slot D
c
OUTDGGIO16 Ind01.stVal–Ind04.stVal Digital Outputs (OUT401–OUT404)—Slot D
c
INEGGIO17 Ind01.stVal–Ind08.stVal Digital Inputs (IN501–IN508)—Slot E
c
OUTEGGIO18 Ind01.stVal–Ind04.stVal Digital Outputs (OUT501–OUT504)—Slot E
c
VBGGIO19 Ind001.stVal–Ind128.stVal Virtual Bits (VB001–VB128)
a
Active data depends on the EMV setting.
b
Active data depends on the ESC setting.
c
Active data only if an I/O card is installed in the slot.
d
Active data depends on the ESV setting.
e
Active data depends on the ELT setting.
