C.9

Date Code 20081022 Instruction Manual SEL-787 Relay

SEL Communications Processors

SEL Communications Processor and Relay Architecture

Table C.8 Communications Processor METER Region Map

Item Starting Address Ty pe

_YEAR 2000h int

DAY_OF_YEAR 2001h int

TIME(ms) 2002h int[2]

MONTH 2004h char

DATE 2005h char

YEAR 2006h char

HOUR 2007h char

MIN 2008h char

SECONDS 2009h char

MSEC 200Ah int

IAW1 200Bh float

IBW1 200Dh float

ICW1 200Fh float

IAW2 2011h float

IBW2 2013h float

ICW2 2015h float

IN 2017h float

VAB 2019h float

VBC 201Bh float

VCA 201Dh float

P 201Fh float

Q 2021h float

S 2023h float

PF 2025h float

FREQ 2027h float

V/HZ 2029h float
