4.88
SEL-787 Relay Instruction Manual Date Code 20081022
Protection and Logic Functions
Global Settings (SET G Command)
=>>SET G AI301NAM TERSE <Enter>
Global
AI 301 Settings
AI301 TAG NAME (8 characters)
AI301NAM:= AI301
? TX_TEMP <Enter>
AI301 TYPE (I,V) AI301TYP:= I ? <Enter>
AI301 LOW IN VAL (-20.480 to 20.480 mA) AI301L := 4.000 ? <Enter>
AI301 HI IN VAL (-20.480 to 20.480 mA) AI301H := 20.000 ? <Enter>
AI301 ENG UNITS (16 characters)
AI301EU := mA
? degrees C <Enter>
AI301 EU LOW (-99999.000 to 99999.000) AI301EL := 4.000 ? -50 <Enter>
AI301 EU HI (-99999.000 to 99999.000) AI301EH := 20.000 ? 150 <Enter>
AI301 LO WARN L1 (OFF,-99999.000 to 99999.000) AI301LW1:= OFF ? <Enter>
AI301 LO WARN L2 (OFF,-99999.000 to 99999.000) AI301LW2:= OFF ? <Enter>
AI301 LO ALARM (OFF,-99999.000 to 99999.000) AI301LAL:= OFF ? <Enter>
AI301 HI WARN L1 (OFF,-99999.000 to 99999.000) AI301HW1:= OFF ? 65 <Enter>
AI301 HI WARN L2 (OFF,-99999.000 to 99999.000) AI301HW2:= OFF ? 95 <Enter>
AI301 HI ALARM (OFF,-99999.000 to 99999.000) AI301HAL:= OFF ? 115 <Enter>
AI 302 Settings
AI302 TAG NAME (8 characters)
AI302NAM:= AI302
? END <Enter>
Save changes (Y,N)? Y <Enter>
Settings Saved
=>>
Figure 4.56 Settings to Configure Input 1 as a 4–20 mA Transducer
Measuring Temperatures Between -50°C and 150°C
Analog (DC Transducer) Input Board
Table 4.37 shows the setting prompt, setting range, and factory default settings
for an analog input card in Slot 3. For the name setting (AI301NAM, for
example), enter only alphanumeric and underscore characters. Characters are
not case sensitive, but the device converts all lowercase characters to
uppercase. Although the device accepts alphanumeric characters, the name
AI301NAM setting must begin with an alpha character (A–Z) and not a
number.
Table 4.37 Analog Input Card in Slot 3
Setting Prompt Setting Range
Setting Name :=
Facto ry Defa ul t
AI301 TAG NAME 8 characters 0–9, A–Z, _ AI301NAM := AI301
AI301 TYPE I, V AI301TYP := I
AI301 LOW IN VAL –20.480 to +20.480 mA AI301L := 4.000
AI301 HI IN VAL –20.480 to +20.480 mA AI301H := 20.000
AI301 LOW IN VAL –10.240 to +10.240 V AI301L := 0.000
a
a
Voltage setting range for a voltage transducer, i.e., when AI301TYP := V.
AI301 HI IN VAL –10.240 to +10.240 V AI301H := 10.000
a
AI301 ENG UNITS 16 characters AI301EU := mA
AI301 EU LOW –99999.000 to +99999.000 AI301EL := 4.000
AI301 EU HI –99999.000 to +99999.000 AI301EH := 20.000
AI301 LO WARN 1 OFF, –99999.000 to +99999.000 AI301LW1 := OFF
AI301 LO WARN 2 OFF, –99999.000 to +99999.000 AI301LW1 := OFF
AI301 LO ALARM OFF, –99999.000 to +99999.000 AI301LAL := OFF
AI301 HI WARN 1 OFF, –99999.000 to +99999.000 AI301HW1 := OFF
AI301 HI WARN 2 OFF, –99999.000 to +99999.000 AI301HW2 := OFF
AI301 HI ALARM OFF, –99999.000 to +99999.000 AI301HAL := OFF
