D.25
Date Code 20081022 Instruction Manual SEL-787 Relay
DNP3 Communications
DNP3 Documentation
Default Data Map
The default data map is an automatically generated subset of the reference
map. All data maps are initialized to the default values, based on the SEL-787
part number. Table D.13 shows the SEL-787 default data map. If the default
maps are not appropriate, you can also use the custom DNP mapping
commands SET DNN and SHOW DNN to create the map required for your
application.
Analog Inputs
30, 32, 34 IAW1_MAG–SC32 Analog Quantities from Table K.1 with an “x” in the
DNP column
0Numeric 0
1Numeric 1
Analog Outputs
40, 41 GROUP Active Settings Group
NOOP No operation, no error
Table D.12 DNP3 Reference Data Map (Sheet 2 of 2)
Object Labels Description
Table D.13 DNP3 Default Data Map
Object Default Index Point Label
01, 02 0 ENABLED
1TRIPXFMR
2TRIP1
3TRIP2
4STFAIL
5STSET
6IN101
7IN102
8–99 A portion of these binary inputs can have default values as
described in Binary Inputs on page D.26. Outside that
scope, they contain the value NA.
10, 12 0–31 RB01–RB32 Remote Bits
20, 22 0–31 NA
30, 32, 34 0 IAW1_MAG
1IBW1_MAG
2ICW1_MAG
3 IGW1_MAG
4 IAW2_MAG
5IBW2_MAG
6ICW2_MAG
7 IGW2_MAG
8IAVW1MAG
9IAVW2MAG
10 3I2W1MAG
11 3I2W1MAG
12 FREQ
13–99 A portion of these analog inputs can have default values as
described in Analog Inputs on page D.26. Outside that
scope, they contain the value NA.
40, 41 0–31 NA
