Schweitzer Engineering Laboratories SEL-787 - Table K.1 Analog Quantities

K.2
SEL-787 Relay Instruction Manual Date Code 20081022
Analog Quantities
Analog Quantities
IBW2_MAG Winding 2 current, B-phase, magnitude A pri x x x x x
IBW2_ANG Winding 2 current, B-phase, angle degrees x x x x
ICW2_MAG Winding 2 current, C-phase, magnitude A pri x x x x x
ICW2_ANG Winding 2 current, C-phase, angle degrees x x x x
IAVW2MAG Winding 2 average current, magnitude A pri x x x x
IGW2_MAG Winding 2 current, calculated-residual,
magnitude
A pri x x x x
IGW2_ANG Winding 2 current, calculated-residual, angle degrees x x x x
3I2W2MAG Winding 2 current, negative-sequence,
magnitude
A pri x x x x
IN_MAG Current, neutral, magnitude A pri x x x x x
IN_ANG Current, neutral, angle degrees x x x x
VA_MAG Voltage, A-phase-to-neutral, magnitude V pri x x x x x
VA_ANG Voltage, A-phase-to-neutral, angle degrees x x x x
VB_MAG Voltage, B-phase-to-neutral, magnitude V pri x x x x x
VB_ANG Voltage, B-phase-to-neutral, angle degrees x x x x
VC_MAG Voltage, C-phase-to-neutral, magnitude V pri x x x x x
VC_ANG Voltage, C-phase-to-neutral, angle degrees x x x x
VAB_MAG Voltage, A-to-B-phase, magnitude V pri x x x x x
VAB_ANG Voltage, A-to-B-phase, angle degrees x x x x
VBC_MAG Voltage, B-to-C-phase, magnitude V pri x x x x x
VBC_ANG Voltage, B-to-C-phase, angle degrees x x x x
VCA_MAG Voltage, C-to-A-phase, magnitude V pri x x x x x
VCA_ANG Voltage, C-to-A-phase, angle degrees x x x x
VG_MAG Zero Sequence Voltage, magnitude V pri x x x x x
VG_ANG Zero Sequence Voltage, angle degrees x x x x
VAVE_MAG Average voltage, magnitude V pri x x x x
3V2_MAG Voltage, negative-sequence, magnitude V pri x x x x
P Real power magnitude, 3-phase kW pri x x x x x
Q Reactive power magnitude, 3-phase kVAR pri x x x x x
S Apparent power magnitude, 3-phase kVA pri x x x x x
PF Power factor, magnitude 3-phase unitless x x x x x
FREQ Frequency Hz x x x x x
VHZ V/Hz % x x x x x
Thermal Metering
RTDAMB Ambient RTD Temperature °C x x x x
RTDOTHMX Other Maximum RTD Temperature °C x x x x
RTD1 to
RTD12
RTD1 to RTD12 Temperature °C x x x x
