Schweitzer Engineering Laboratories SEL-787 - Table F.11 Logical Device: MET (Metering)

F.16
SEL-787 Relay Instruction Manual Date Code 20081022
IEC 61850 Communications
Logical Nodes
Table F.11 shows the LN associated with measuring elements defined as
Logical Device MET.
Table F.11 Logical Device: MET (Metering) (Sheet 1 of 3)
Logical Node Measurand Comment
Fundamental Metering
METMMXU1 TotW.mag Three-phase Real Power P Magnitude
a
METMMXU1 TotVAr.mag Three-phase Reactive Power Q Magnitude
a
METMMXU1 TotVA.mag Three-phase Apparent Power S Magnitude
a
METMMXU1 TotPF.mag Three-phase Power Factor
a
METMMXU1 Hz.mag Measured frequency
METMMXU1 PPV.phsAB.cVal.mag AB-phase voltage magnitude when DELTA_Y=D
a
METMMXU1 PPV.phsAB.cVal.ang AB-phase voltage angle when DELTA_Y=D
a
METMMXU1 PPV.phsBC.cVal.mag BC-phase voltage magnitude when DELTA_Y=D
a
METMMXU1 PPV.phsBC.cVal.ang BC-phase voltage angle when DELTA_Y=D
a
METMMXU1 PPV.phsCA.cVal.mag CA-phase voltage magnitude when DELTA_Y=D
a
METMMXU1 PhV.phsA.cVal.mag A-phase voltage magnitude when DELTA_Y=Y
a
METMMXU1 PhV.phsA.cVal.ang A-phase voltage angle when DELTA_Y=Y
a
METMMXU1 PhV.phsB.cVal.mag B-phase voltage magnitude when DELTA_Y=Y
a
METMMXU1 PhV.phsB.cVal.ang B-phase voltage angle when DELTA_Y=Y
a
METMMXU1 PhV.phsC.cVal.mag C-phase voltage magnitude when DELTA_Y=Y
a
METMMXU1 PhV.phsC.cVal.ang C-phase voltage angle when DELTA_Y=Y
a
METMMXU1 PhV.res.cVal.mag Residual voltage magnitude when DELTA_Y=Y
a
METMMXU1 PhV.res.cVal.ang Residual voltage angle when DELTA_Y=Y
a
METMMXU1 A1.phsA.cVal.mag Winding1 A-phase current magnitude
METMMXU1 A1.phsA.cVal.ang Winding1 A-phase current angle
METMMXU1 A1.phsB.cVal.mag Winding1 B-phase current magnitude
METMMXU1 A1.phsB.cVal.ang Winding1 B-phase current angle
METMMXU1 A1.phsC.cVal.mag Winding1 C-phase current magnitude
METMMXU1 A1.phsC.cVal.ang Winding1 C-phase current angle
METMMXU1 A1.res.cVal.mag Winding1 Residual current magnitude
METMMXU1 A1.res.cVal.ang Winding1 Residual current angle
METMMXU1 A2.phsA.cVal.mag Winding2 A-phase current magnitude
METMMXU1 A2.phsA.cVal.ang Winding2 A-phase current angle
METMMXU1 A2.phsB.cVal.mag Winding2 B-phase current magnitude
METMMXU1 A2.phsB.cVal.ang Winding2 B-phase current angle
METMMXU1 A2.phsC.cVal.mag Winding2 C-phase current magnitude
METMMXU1 A2.phsC.cVal.ang Winding2 C-phase current angle
METMMXU1 A2.res.cVal.mag Winding2 Residual current magnitude
METMMXU1 A2.res.cVal.ang Winding2 Residual current angle
METMMXU1 A.neut.cVal.mag Neutral current magnitude
METMMXU1 A.neut.cVal.ang Neutral current angle
