Schweitzer Engineering Laboratories SEL-787 - Page 349

9.15
Date Code 20081022 Instruction Manual SEL-787 Relay
Analyzing Events
Event Reporting
51G2 *
t
r
51G2P picked up
51G2T picked up
51G2R picked up
51Q2 *
t
r
51Q2P picked up
51Q2T picked up
51Q2R picked up
50N1 *
t
50N1P picked up
50N1T picked up
50N2 *
t
50N2P picked up
50N2T picked up
51N1 *
t
r
51N1P picked up
51N1T picked up
51N1R picked up
27P1 *
t
27P1 picked up
27P1T picked up
27P2 *
t
27P2 picked up
27P2T picked up
59P1 *
t
59P1 picked up
59P1T picked up
59P2 *
t
59P2 picked up
59P2T picked up
24D1 1
D
24D1 picked up
24D1T picked up
24C2 2
C
r
24C2 picked up
24C2T picked up
24CR picked up
3PW1 *
t
3PWR1P picked up
3PWR1T picked up
3PW2 *
t
3PWR2P picked up
3PWR2T picked up
81D12 1
2
b
81D1T picked up
81D2T picked up
Both 81D1T and 81D2T picked up
81D34 3
4
b
81D3T picked up
81D4T picked up
Both 81D3T and 81D4T picked up.
BFI1 *
t
BFI1 picked up
BFT1 picked up
BFI2 *
t
BFI2 picked up
BFT2 picked up
TRIP * TRIP picked up
REF *
f
r
REF1P picked up
REF1F picked up
REF1R picked up
Inputs 3012 1
2
b
IN301 picked up
IN302 picked up
Both IN301 and IN302 picked up
Inputs 3034 3
4
b
IN303 picked up
IN304 picked up
Both IN303 and IN304 picked up
Table 9.3 Digital Event Report Column Definitions (Sheet 2 of 4)
Column Designation
Column
Symbols
Column Symbol Relay Word Bits (RWB)
