Date _______________
Group______________
Date Code 20081022 Instruction Manual SEL-787 Relay
SET.5
of 68
SEL-787 Settings Sheets
Group Settings (SET Command)
PHASE IOC DELAY (0.00–5.00 sec)
(Hidden if 50P24P := OFF)
50P24D :=
PH IOC TRQCTRL (SEL
OGIC) (Hidden if 50P24P := OFF) 50P24TC :=
Winding 2 Residual Overcurrent
All settings below are hidden when W2CT := DELTA.
RES IOC LEVEL (OFF, 0.50–96.00 A [5 A nom.],
0.10–19.20 A [1 A nom.])
50G21P :=
RES IOC DELAY (0.00–5.00 sec)
(Hidden if 50G21P := OFF) 50G21D :=
RES IOC TRQCTRL (SEL
OGIC) (Hidden if 50G21P := OFF) 50G21TC :=
RES IOC LEVEL (OFF, 0.50–96.00 A [5 A nom.],
0.10–19.20 A [1 A nom.])
50G22P :=
RES IOC DELAY (0.00–5.00 sec)
(Hidden if 50G22P := OFF) 50G22D :=
RES IOC TRQCTRL (SEL
OGIC) (Hidden if 50G22P := OFF) 50G22TC :=
Winding 2 Negative-Sequence Overcurrent
NSEQ IOC LEVEL (OFF, 0.50–96.00 A [5 A nom.],
0.10–19.20 A [1 A nom.])
50Q21P :=
NSEQ IOC DELAY (0.00–5.00 sec)
(Hidden if 50Q21P := OFF)
50Q21D :=
NSEQ IOC TRQCTRL (SEL
OGIC)
(Hidden if 50Q21P := OFF)
50Q21TC :=
NSEQ IOC LEVEL (OFF, 0.50–96.00 A [5 A nom.],
0.10–19.20 A [1 A nom.])
50Q22P :=
NSEQ IOC DELAY (0.00–5.00 sec)
(Hidden if 50Q22P := OFF)
50Q22D :=
NSEQ IOC TRQCTRL (SEL
OGIC)
(Hidden if 50Q22P := OFF)
50Q22TC :=
Winding 2 Maximum Phase Time Overcurrent
PHASE TOC LEVEL (OFF, 0.50–16.00 A [5 A nom.], 0.10–
3.20 A [1 A nom.])
51P2P :=
PHASE TOC CURVE (U1, U2, U3, U4, U5, C1, C2, C3, C4,
C5)
(Hidden if 51P2P := OFF)
51P2C :=
PHASE TOC TDIAL (0.50–15.00 for U1–U5 OR 0.05–1.00 for
C1–C5)
(Hidden if 51P2P := OFF)
51P2TD :=
EM RESET DELAY (Y, N)
(Hidden if 51 N1P := OFF) 51P2RS :=
CONST TIME ADDER (0.00–1.00 sec)
(Hidden if 51P2P := OFF)
51P2CT :=
MIN RESPONSE TIM (0.00–1.00 sec)
(Hidden if 51P2P := OFF)
51P2MR :=
PH TOC TRQCTRL (SEL
OGIC) (Hidden if 51P2P := OFF) 51P2TC :=
Winding 2 Residual Time Overcurrent
All settings below are hidden when W2CT := DELTA.
RES TOC LEVEL (OFF, 0.50–16.00 A [5 A nom.], 0.10–3.20
A [1 A nom.])
51G2P :=
