Schweitzer Engineering Laboratories SEL-787 - Page 220

SET.8
of 68
SEL-787 Settings Sheets
Group Settings (SET Command)
SEL-787 Relay Instruction Manual Date Code 20081022
Date _______________
Group______________
RTD5 LOCATION (OFF, AMB, OTH) RTD5LOC :=
RTD5 IDENTIFIER (10 characters)
(Hidden if RTD5LOC := OFF or AMB)
RTD5NAM :=
RTD5 TYPE (PT100, NI100, NI120, CU10)
(Hidden if RTD5LOC := OFF)
RTD5TY :=
RTD5 TRIP LEVEL (OFF, 1–250 degC)
(Hidden if RTD5LOC := OFF)
TRTMP5 :=
RTD5 WARN LEVEL (OFF, 1–250 degC)
(Hidden if RTD5LOC := OFF)
ALTMP5 :=
RTD6 LOCATION (OFF, AMB, OTH)
RTD6LOC :=
RTD6 IDENTIFIER (10 characters)
(Hidden if RTD6LOC := OFF or AMB)
RTD6NAM :=
RTD6 TYPE (PT100, NI100, NI120, CU10)
(Hidden if RTD6LOC := OFF)
RTD6TY :=
RTD6 TRIP LEVEL (OFF, 1–250 degC)
(Hidden if RTD6LOC := OFF)
TRTMP6 :=
RTD6 WARN LEVEL (OFF, 1–250 degC)
(Hidden if RTD6LOC := OFF)
ALTMP6 :=
RTD7 LOCATION (OFF, AMB, OTH)
RTD7LOC :=
RTD7 IDENTIFIER (10 characters)
(Hidden if RTD7LOC := OFF or AMB)
RTD7NAM :=
RTD7 TYPE (PT100, NI100, NI120, CU10)
(Hidden if RTD7LOC := OFF)
RTD7TY :=
RTD7 TRIP LEVEL (OFF, 1–250 degC)
(Hidden if RTD7LOC := OFF)
TRTMP7 :=
RTD7 WARN LEVEL (OFF, 1–250 degC)
(Hidden if RTD7LOC := OFF)
ALTMP7 :=
RTD8 LOCATION (OFF, AMB, OTH)
RTD8LOC :=
RTD8 IDENTIFIER (10 characters)
(Hidden if RTD8LOC := OFF or AMB)
RTD8NAM :=
RTD8 TYPE (PT100, NI100, NI120, CU10)
(Hidden if RTD8LOC := OFF)
RTD8TY :=
RTD8 TRIP LEVEL (OFF, 1–250 degC)
(Hidden if RTD8LOC := OFF)
TRTMP8 :=
RTD8 WARN LEVEL (OFF, 1–250 degC)
(Hidden if RTD8LOC := OFF)
ALTMP8 :=
RTD9 LOCATION (OFF, AMB, OTH)
RTD9LOC :=
RTD9 IDENTIFIER (10 characters)
(Hidden if RTD9LOC := OFF or AMB)
RTD9NAM :=
RTD9 TYPE (PT100, NI100, NI120, CU10)
(Hidden if RTD9LOC := OFF)
RTD9TY :=
RTD9 TRIP LEVEL (OFF, 1–250 degC)
(Hidden if RTD9LOC := OFF)
TRTMP9 :=
RTD9 WARN LEVEL (OFF, 1–250 degC)
(Hidden if RTD9LOC := OFF)
ALTMP9 :=
