Schweitzer Engineering Laboratories SEL-787 - Page 227

Date _______________
Group______________
Date Code 20081022 Instruction Manual SEL-787 Relay
SET.15
of 68
SEL-787 Settings Sheets
Logic Settings (SET L Command)
SV/Timers
SV TIMER PICKUP (0.00–3000.00 sec) SV01PU :=
SV TIMER DROPOUT (0.00–3000.00 sec)
SV01DO :=
SV INPUT (
SELOGIC) SV01 :=
SV TIMER PICKUP (0.00–3000.00 sec)
SV02PU :=
SV TIMER DROPOUT (0.00–3000.00 sec)
SV02DO :=
SV INPUT (
SELOGIC) SV02 :=
SV TIMER PICKUP (0.00–3000.00 sec)
SV03PU :=
SV TIMER DROPOUT (0.00–3000.00 sec)
SV03DO :=
SV INPUT (
SELOGIC) SV03 :=
SV TIMER PICKUP (0.00–3000.00 sec)
SV04PU :=
SV TIMER DROPOUT (0.00–3000.00 sec)
SV04DO :=
SV INPUT (
SELOGIC) SV04 :=
SV TIMER PICKUP (0.00–3000.00 sec)
SV05PU :=
SV TIMER DROPOUT (0.00–3000.00 sec)
SV05DO :=
SV INPUT (
SELOGIC) SV05 :=
SV TIMER PICKUP (0.00–3000.00 sec)
SV06PU :=
SV TIMER DROPOUT (0.00–3000.00 sec)
SV06DO :=
SV INPUT (
SELOGIC) SV06 :=
SV TIMER PICKUP (0.00–3000.00 sec)
SV07PU :=
SV TIMER DROPOUT (0.00–3000.00 sec)
SV07DO :=
SV INPUT (
SELOGIC) SV07 :=
SV TIMER PICKUP (0.00–3000.00 sec)
SV08PU :=
SV TIMER DROPOUT (0.00–3000.00 sec)
SV08DO :=
SV INPUT (
SELOGIC) SV08 :=
SV TIMER PICKUP (0.00–3000.00 sec)
SV09PU :=
SV TIMER DROPOUT (0.00–3000.00 sec)
SV09DO :=
SV INPUT (
SELOGIC) SV09 :=
SV TIMER PICKUP (0.00–3000.00 sec)
SV10PU :=
SV TIMER DROPOUT (0.00–3000.00 sec)
SV10DO :=
SV INPUT (
SELOGIC) SV10 :=
SV TIMER PICKUP (0.00–3000.00 sec)
SV11PU :=
SV TIMER DROPOUT (0.00–3000.00 sec)
SV11DO :=
SV INPUT (
SELOGIC) SV11 :=
SV TIMER PICKUP (0.00–3000.00 sec)
SV12PU :=
SV TIMER DROPOUT (0.00–3000.00 sec)
SV12DO :=
SV INPUT (
SELOGIC) SV12 :=
