SEL-787 Settings Sheets
SET PORT p (p = F, 1, 2, 3, or 4) Command
Session 3
All Session 3 settings are hidden if EDNP < 3.
IP Address [zzz.yyy.xxx.www] (15 characters)
DNPIP3 :=
Transport Protocol (UDP, TCP)
DNPTR3 :=
UDP Response Port (REQ, 1–65534)
DNPUDP3 :=
DNP Address to Report to (0–65519)
REPADR3 :=
DNP Map (1–3)
DNPMAP3 :=
Analog Input Default Variation (1–6)
DVARAI3 :=
Class for Binary Event Data (0–3)
ECLASSB3 :=
Class for Counter Event Data (0–3)
ECLASSC3 :=
Class for Analog Event Data (0–3)
ECLASSA3 :=
Currents Scaling Decimal Places (0–3)
DECPLA3 :=
Voltages Scaling Decimal Places (0–3)
DECPLV3 :=
Misc Data Scaling Decimal Places (0–3)
DECPLM3 :=
Amps Reporting Deadband Counts (0–32767)
(Hidden if ECLASSA3 := 0)
ANADBA3 :=
Volts Reporting Deadband Counts (0–32767)
(Hidden if ECLASSA3 := 0)
ANADBV3 :=
Misc Data Reporting Deadband Counts (0–32767)
(Hidden if ECLASSA3 := 0 and ECLASSC3 := 0)
ANADBM3 :=
Minutes for Request Interval (I, M, 1–32767)
TIMERQ3 :=
Seconds to Select/Operate Time-Out (0.0–30.0)
STIMEO3 :=
Seconds to send Data Link Heartbeat (0–7200)
(Hidden if DNPTR3 := UDP)
DNPINA3 :=
Event Message Confirm Time-Out (1–50 sec))
ETIMEO3 :=
Enable Unsolicited Reporting (Y, N)
(Hidden if ECLASSA3 := 0, ECLASSB3 := 0, ECLASSC3 := 0, and
ECLASSV3 := 0)
UNSOL3 :=
Enable Unsolicited Reporting at Power-Up (Y, N)
(Hidden if UNSOL3 := N)
PUNSOL3 :=
Number of Events to Transmit On (1–200)
(Hidden if UNSOL3 := N)
NUMEVE3 :=
Oldest Event to Tx On (0.0–99999.0 sec)
(Hidden if UNSOL3 := N)
AGEEVE3 :=
Unsolicited Message Max Retry Attempts (2–10)
(Hidden if UNSOL3 := N)
URETRY3 :=
Unsolicited Message Offline Time-Out (1–5000 sec)
(Hidden if UNSOL3 := N)
UTIMEO3 :=
