SEL-787 Settings Sheets
SET PORT p (p = F, 1, 2, 3, or 4) Command
SEL-787 Relay Instruction Manual Date Code 20081022
Date _______________
Group______________
RMB4 Dropout Debounce Messages (1–8) RMB4DO :=
RMB5 Pickup Debounce Messages (1–8)
RMB5PU :=
RMB5 Dropout Debounce Messages (1–8)
RMB5DO :=
RMB6 Pickup Debounce Messages (1–8)
RMB6PU :=
RMB6 Dropout Debounce Messages (1–8)
RMB6DO :=
RMB7 Pickup Debounce Messages (1–8)
RMB7PU :=
RMB7 Dropout Debounce Messages (1–8)
RMB7DO :=
RMB8 Pickup Debounce Messages (1–8)
RMB8PU :=
RMB8 Dropout Debounce Messages (1–8)
RMB8DO :=
PORT 4 (EIA-232/485 Port or DeviceNet Port in Slot C)
PROTOCOL (SEL, DNP, MOD, DNET, EVMSG, PMU, MBA,
MBB, MB8A, MB8B, MBTA, MBTB)
PROTO :=
Interface Select
(Hidden if PROTO := DNET.)
COMM INTERFACE (232, 485) COMMINF :=
Communications
SPEED (300, 1200, 2400, 4800, 9600, 19200, 38400 bps)
(Hidden if PROTO := DNET)
SPEED :=
DATA BITS (7, 8 bits)
(Hidden if PROTO := DNP, MOD, PMU,
EVMSG, MB_, or DNET)
BITS :=
PARITY (O, E, N)
(Hidden if PROTO := DNET, EVMSG, PMU, or
MB_)
PARITY :=
STOP BITS (1, 2 bits)
(Hidden if PROTO := MOD, EVMSG, MB_,
or DNET)
STOP :=
PORT TIME-OUT (0–30 min)
(Hidden if PROTO :=MOD,
EVMSG, MB_, PMU or DNET)
T_OUT :=
SEND AUTOMESSAGE (Y, N)
(Hidden if PROTO :=DNP, MOD,
EVMSG, MB_, PMU or DNET)
AUTO :=
HDWR HANDSHAKING (Y, N)
(Hidden if COMMINF :=485 or
PROTO := MOD, DNP, EVMSG, MB_, or DNET)
RTSCTS :=
FAST OP MESSAGES (Y, N)
(Hidden if PROTO := DNP, MOD,
EVMSG, MB_, PMU or DNET)
FASTOP :=
DNP3 Protocol
(Hidden if PROTO := SEL, EVMSG, MB, PMU , DNET or MOD.)
DNP Address (0–65519) DNPADR :=
DNP Address to Report to (0–65519)
REPADR1 :=
DNP Map (1–3)
DNPMAP1 :=
Analog Input Default Variation (1–6)
DVARAI1 :=
Class for Binary Event Data (0–3)
ECLASSB1 :=
Class for Counter Event Data (0–3)
ECLASSC1 :=
Class for Analog Event Data (0–3)
ECLASSA1 :=
