Schweitzer Engineering Laboratories SEL-787 - Page 256

SET.44
of 68
SEL-787 Settings Sheets
SET PORT p (p = F, 1, 2, 3, or 4) Command
SEL-787 Relay Instruction Manual Date Code 20081022
Date _______________
Group______________
Modbus Protocol
MODBUS SLAVE ID (1–247) (Hidden if PROTO := SEL, DNP,
PMU, EVMSG, MB_, or DNET)
SLAVEID :=
MIRRORED BITS Protocol
(Hidden if PROTO := SEL, EVMSG, DNP, PMU, DNET or MOD.)
MB Transmit Identifier (1–4) TXID :=
MB Receive Identifier (1–4)
RXID :=
MB RX Bad Pickup Time (0–10000 seconds)
RBADPU :=
PPM MB Channel Bad Pickup (1–10000)
CBADPU :=
MB Receive Default State (8 characters)
RXDFLT :=
RMB1 Pickup Debounce Messages (1–8)
RMB1PU :=
RMB1 Dropout Debounce Messages (1–8)
RMB1DO :=
RMB2 Pickup Debounce Messages (1–8)
RMB2PU :=
RMB2 Dropout Debounce Messages (1–8)
RMB2DO :=
RMB3 Pickup Debounce Messages (1–8)
RMB3PU :=
RMB3 Dropout Debounce Messages (1–8)
RMB3DO :=
RMB4 Pickup Debounce Messages (1–8)
RMB4PU :=
RMB4 Dropout Debounce Messages (1–8)
RMB4DO :=
RMB5 Pickup Debounce Messages (1–8)
RMB5PU :=
RMB5 Dropout Debounce Messages (1–8)
RMB5DO :=
RMB6 Pickup Debounce Messages (1–8)
RMB6PU :=
RMB6 Dropout Debounce Messages (1–8)
RMB6DO :=
RMB7 Pickup Debounce Messages (1–8)
RMB7PU :=
RMB7 Dropout Debounce Messages (1–8)
RMB7DO :=
RMB8 Pickup Debounce Messages (1–8)
RMB8PU :=
RMB8 Dropout Debounce Messages (1–8)
RMB8DO :=
