9.20
SEL-787 Relay Instruction Manual Date Code 20081022
Analyzing Events
Event Reporting
=>>EVE DIF1 (Enter)
SEL-787 Date: 02/14/2008 Time: 13:09:57.353
TRNSFRMR RELAY
Serial Number=000000000000000
FID=SEL-787-X122HR-V0-Z001001-D20080212 CID=26FF
Differential O
Differential Quantities 8 87 87 87 87 I u
Multiples of TAP (Amps Api) 7 R U B HR HB T n t
R 13 13 13 13 H 1 13
IOP1 IRT1 I1F2 I1F5 2 2 2 2 123 5 2 2
[1]
919.5 561.9 0.0 2.9 . .. .. .. .. ... . . ..
919.5 561.9 5.5 5.8 . .. .. .. .. ... . . ..
920.9 562.6 0.3 5.0 . .. .. .. .. ... . . ..
923.4 563.6 2.6 2.4 . .. .. .. .. ... . . ..
[2]
923.3 563.6 2.4 3.4 . .. .. .. .. ... . . ..
918.5 561.4 2.4 5.8 . .. .. .. .. ... . . ..
918.5 561.4 2.4 5.3 . .. .. .. .. ... . . ..
923.3 563.6 2.6 0.2 . .. .. .. .. ... . . ..
[3]
922.6 563.3 0.0 2.6 . .. .. .. .. ... . . ..
917.7 561.2 3.6 5.7 . .. .. .. .. ... . . ..
919.8 561.5 0.5 6.5 . .. .. .. .. ... . . ..
882.0 583.2 19.1 4.8 . .. .. b* .. 2.. . . ..
[4]
876.0 585.0 39.6 7.2 . .. .. b* .. 2.. . . ..
809.7 618.5 19.0 7.3 . .. .. b* .. 2.. . . ..
804.6 621.3 0.8 2.9 . .. .. .. .. ... . . ..
781.6 635.1 2.4 0.2 . .. .. .. .. ... . . ..
[5]
780.8 634.9 2.9 2.6 . 1. .. .. .. ... . . ..
778.3 633.8 2.6 5.7 . 1. .. .. .. ... . . ..
779.7 634.5 2.9 5.0 . 1. .. .. .. ... . . ..
782.3 635.5 2.4 2.4> * 1. .. .. 1. ... . . ..
[6]
781.4 635.2 2.6 2.4 * 1. .. .. 1. ... . . .*
776.6 633.1 2.6 5.0 * 1. .. .. 1. ... . . .*
777.4 633.3 2.6 5.0 * 1. .. .. 1. ... . . .*
780.0 634.4 0.2 0.2 * 1. .. .. 1. ... . . .*
[7]
779.1 634.1 2.6 5.0 * 1. .. .. 1. ... . . .*
776.6 633.1 2.4 5.6 * 1. .. .. 1. ... . . .*
777.3 633.4 2.6 2.4 * 1. .. .. 1. ... . . .*
780.1 634.3 2.4 0.2 * 1. .. .. 1. ... . . .*
[8]
780.0 634.3 3.4 2.6 * 1. .. .. 1. ... . . .*
777.5 633.3 2.6 5.5 * 1. .. .. 1. ... . . .*
777.5 633.3 0.0 4.8 * 1. .. .. 1. ... . . .*
782.1 635.6 3.7 2.4 * 1. .. .. 1. ... . . .*
[9]
781.3 635.3 2.4 3.4 * 1. .. .. 1. ... . . .*
776.7 633.0 2.4 3.7 * 1. .. .. 1. ... . . .*
778.2 633.6 0.2 2.9 * 1. .. .. 1. ... . . .*
780.7 634.7 2.4 0.0 * 1. .. .. 1. ... . . .*
[10]
779.9 634.4 2.6 5.3 * 1. .. .. 1. ... . . .*
777.1 633.5 4.8 5.8 * 1. .. .. 1. ... . . .*
777.8 633.8 2.6 3.2 * 1. .. .. 1. ... . . .*
782.6 636.0 0.2 3.4 * 1. .. .. 1. ... . . .*
[11]
782.5 636.1 2.6 3.6 * 1. .. .. 1. ... . . .*
777.9 633.8 3.4 3.6 * 1. .. .. 1. ... . . .*
777.9 633.7 0.3 2.6 * 1. .. .. 1. ... . . .*
780.7 634.7 5.6 2.2 * 1. .. .. 1. ... . . .*
[12]
779.9 634.4 0.2 3.4 * 1. .. .. 1. ... . . .*
777.4 633.3 4.8 5.5 * 1. .. .. 1. ... . . .*
778.1 633.7 3.2 4.8 * 1. .. .. 1. ... . . .*
780.6 634.7 3.7 0.0 * 1. .. .. 1. ... . . .*
[13]
780.6 634.7 0.2 2.6 * 1. .. .. 1. ... . . .*
778.0 633.7 3.6 5.7 * 1. .. .. 1. ... . . .*
779.4 634.4 2.4 5.0 * 1. .. .. 1. ... . . .*
781.9 635.4 2.4 2.2 * 1. .. .. 1. ... . . .*
[14]
781.2 635.1 0.2 3.4 * 1. .. .. 1. ... . . .*
778.4 634.2 3.6 5.5* * 1. .. .. 1. ... . . .*
779.2 634.5 2.6 4.8 * 1. .. .. 1. ... . . .*
779.7 634.3 2.6 2.4 * 1. .. .. 1. ... . . .*
NOTE: The Event Summary and
Settings are not shown here as they
are the same as in Figure 9.3.
