Schweitzer Engineering Laboratories SEL-787 - Page 424

E.10
SEL-787 Relay Instruction Manual Date Code 20081022
Modbus RTU Communications
Communications Protocol
5 01, 05 Pulse OUT303 1 second
6 01, 05 Pulse OUT304 1 second
7 01, 05 Reserved
8 01, 05 Reserved
9 01, 05 Reserved
10 01, 05 Reserved
11 01, 05 Pulse OUT401 1 second
12 01, 05 Pulse OUT402 1 second
13 01, 05 Pulse OUT403 1 second
14 01, 05 Pulse OUT404 1 second
15 01, 05 Reserved
16 01, 05 Reserved
17 01, 05 Reserved
18 01, 05 Reserved
19 01, 05 Pulse OUT501 1 second
20 01, 05 Pulse OUT502 1 second
21 01, 05 Pulse OUT503 1 second
22 01, 05 Pulse OUT504 1 second
23 01, 05 Reserved
24 01, 05 Reserved
25 01, 05 Reserved
26 01, 05 Reserved
27 01, 05 RB01
28 01, 05 RB02
29 01, 05 RB03
30 01, 05 RB04
31 01, 05 RB05
32 01, 05 RB06
33 01, 05 RB07
34 01, 05 RB08
35 01, 05 RB09
36 01, 05 RB10
37 01, 05 RB11
38 01, 05 RB12
39 01, 05 RB13
40 01, 05 RB14
41 01, 05 RB15
42 01, 05 RB16
43 01, 05 RB17
44 01, 05 RB18
45 01, 05 RB19
46 01, 05 RB20
47 01, 05 RB21
48 01, 05 RB22
Table E.14 01h, 05h SEL-787 Output (Sheet 2 of 3)
Coil Address (Decimal) Function Code Supported Coil Description
