Schweitzer Engineering Laboratories SEL-787 - Page 434

E.20
SEL-787 Relay Instruction Manual Date Code 20081022
Modbus RTU Communications
Communications Protocol
Instructi on Manual
Table E.31 Modbus Register Labels for Use With SET M Command (Sheet 2 of 3)
848 KVA3PMX
849 KVA3PMN
850 FREQMX
851 FREQMN
852 RTD1MX
853 RTD1MN
854 RTD2MX
855 RTD2MN
856 RTD3MX
857 RTD3MN
858 RTD4MX
859 RTD4MN
860 RTD5MX
861 RTD5MN
862 RTD6MX
863 RTD6MN
864 RTD7MX
865 RTD7MN
866 RTD8MX
867 RTD8MN
868 RTD9MX
869 RTD9MN
870 RTD10MX
871 RTD10MN
872 RTD11MX
873 RTD11MN
874 RTD12MX
875 RTD12MN
876 AI301MXH
877 AI301MXL
878 AI301MNH
879 AI301MNL
880 AI302MXH
881 AI302MXL
882 AI302MNH
883 AI302MNL
884 AI303MXH
885 AI303MXL
886 AI303MNH
887 AI303MNL
888 AI304MXH
889 AI304MXL
890 AI304MNH
891 AI304MNL
892 AI401MXH
893 AI401MXL
894 AI401MNH
895 AI401MNL
896 AI402MXH
897 AI402MXL
898 AI402MNH
Register
Address
Label
899 AI402MNL
900 AI403MXH
901 AI403MXL
902 AI403MNH
903 AI403MNL
904 AI403MXH
905 AI403MXL
906 AI404MNH
907 AI404MNL
908 AI501MXH
909 AI501MXL
910 AI501MNH
911 AI501MNL
912 AI502MXH
913 AI502MXL
914 AI502MNH
915 AI502MNL
916 AI503MXH
917 AI503MXL
918 AI503MNH
919 AI503MNL
920 AI504MXH
921 AI504MXL
922 AI504MNH
923 AI504MNL
924 MXMN_R_S
925 MXMN_RMN
926 MXMN_R_H
927 MXMN_R_D
928 MXMN_RMO
929 MXMN_R_Y
930 RES_930
931 RES_931
932 RES_932
933 RES_933
934 RES_934
935 RES_935
936 RES_936
937 RES_937
938 RES_938
939 RES_939
940 AI301H
941 AI301L
942 AI302H
943 AI302L
944 AI303H
945 AI303L
946 AI304H
947 AI304L
948 AI401H
949 AI401L
Register
Address
Label
950 AI402H
951 AI402L
952 AI403H
953 AI403L
954 AI404H
955 AI404L
956 AI501H
957 AI501L
958 AI502H
959 AI502L
960 AI503H
961 AI503L
962 AI504H
963 AI504L
964 RES_964
965 RES_965
966 RES_966
967 RES_967
968 RES_968
969 RES_969
970 MV01H
971 MV01L
972 MV02H
973 MV02L
974 MV03H
975 MV03L
976 MV04H
977 MV04L
978 MV05H
979 MV05L
980 MV06H
981 MV06L
982 MV07H
983 MV07L
984 MV08H
985 MV08L
986 MV09H
987 MV09L
988 MV10H
989 MV10L
990 MV11H
991 MV11L
992 MV12H
993 MV12L
994 MV13H
995 MV13L
996 MV14H
997 MV14L
998 MV15H
999 MV15L
1000 MV16H
Register
Address
Label
1001 MV16L
1002 MV17H
1003 MV17L
1004 MV18H
1005 MV18L
1006 MV19H
1007 MV19L
1008 MV20H
1009 MV20L
1010 MV21H
1011 MV21L
1012 MV22H
1013 MV22L
1014 MV23H
1015 MV23L
1016 MV24H
1017 MV24L
1018 MV25H
1019 MV25L
1020 MV26H
1021 MV26L
1022 MV27H
1023 MV27L
1024 MV28H
1025 MV28L
1026 MV29H
1027 MV29L
1028 MV30H
1029 MV30L
1030 MV31H
1031 MV31L
1032 MV32H
1033 MV32L
1034 SC01
1035 SC02
1036 SC03
1037 SC04
1038 SC05
1039 SC06
1040 SC07
1041 SC08
1042 SC09
1043 SC10
1044 SC11
1045 SC12
1046 SC13
1047 SC14
1048 SC15
1049 SC16
1050 SC17
1051 SC18
Register
Address
Label
