Schweitzer Engineering Laboratories SEL-787 - Page 450

E.36
SEL-787 Relay Instruction Manual Date Code 20081022
Modbus RTU Communications
Modbus Register Map
551 (R/W) DEM TIME CONSTNT min 0 4 0 651
0=5
1=10
2=15
3=30
4=60
552 (R/W) PH CURR DEM LVL A 1 160 50 0.1 652
553 (R/W) RES CURR DEM LVL A 1 160 10 0.1 653
554 (R/W) 3I2 CURR DEM LVL A 1 160 10 0.1 654
555–564 (R) Reserved
c
0 0 0 655–664
Trip/Close Logic
565 (R/W) MIN TRIP TIME sec 0 4000 5 0.1 665
566 (R/W) CLOSE1 FAIL DLY sec 0 4000 5 0.1 666
567 (R/W) CLOSE2 FAIL DLY sec 0 4000 5 0.1 667
568–575 (R) Reserved
c
0 0 0 668–675
SELOGIC Enables
576 (R/W) SELOGIC LATCHES 0 32 4 1 676
577 (R/W) SV/TIMERS 0 32 5 1 677
578 (R/W) SEL
OGIC COUNTERS 0 32 0 1 678
579 (R/W) MATH VARIABLES 0 32 0 1 679
580–584 (R) Reserved
c
0 0 0 680–684
Output Contacts 0 = N 1 = Y
585 (R/W) OUT101 FAIL-SAFE 0 1 1 685
586 (R/W) OUT102 FAIL-SAFE 0 1 0 686
587 (R/W) OUT103 FAIL-SAFE 0 1 0 687
588 (R/W) OUT301 FAIL-SAFE 0 1 0 688
589 (R/W) OUT302 FAIL-SAFE 0 1 0 689
590 (R/W) OUT303 FAIL-SAFE 0 1 0 690
591 (R/W) OUT304 FAIL-SAFE 0 1 0 691
592 (R/W) OUT401 FAIL-SAFE 0 1 0 692
593 (R/W) OUT402 FAIL-SAFE 0 1 0 693
594 (R/W) OUT403 FAIL-SAFE 0 1 0 694
595 (R/W) OUT404 FAIL-SAFE 0 1 0 695
596 (R/W) OUT501 FAIL-SAFE 0 1 0 696
597 (R/W) OUT502 FAIL-SAFE 0 1 0 697
598 (R/W) OUT503 FAIL-SAFE 0 1 0 698
599 (R/W) OUT504 FAIL-SAFE 0 1 0 699
600–604 (R) Reserved
c
0 0 0 700–704
Event Report Set
605 (R/W) EVENT LENGTH cyc 0 1 0 705
0=15
1=64
606 (R/W) PREFAULT LENGTH cyc 1 59 5 1 706
607 (R) Reserved
c
000 707
608 (R/W) ENABLE ALIASES 0 20 4 1 708
Table E.32 Modbus Register Map
a
(Sheet 15 of 38)
Modbus Register
Address
b
Name / Enums Units Min Max Def
Scale
Fa c tor
DeviceNet
Parameter
Numbers
