IEC 61850 Communications
Logical Nodes
G11PIOC11 Str.general 50G11P
G11PIOC11 Op.general 50G11T
G12PIOC12 Str.general 50G12P
G12PIOC12 Op.general 50G12T
G21PIOC13 Str.general 50G21P
G21PIOC13 Op.general 50G21T
G22PIOC14 Str.general 50G22P
G22PIOC14 Op.general 50G22T
Q11PIOC15 Str.general 50Q11P
Q11PIOC15 Op.general 50Q11T
Q12PIOC16 Str.general 50Q12P
Q12PIOC16 Op.general 50Q12T
Q21PIOC17 Str.general 50Q21P
Q21PIOC17 Op.general 50Q21T
Q22PIOC18 Str.general 50Q22P
Q22PIOC18 Op.general 50Q22T
P1PTOC1 Str.general 51P1P
P1PTOC1 Op.general 51P1T
P2PTOC2 Str.general 51P2P
P2PTOC2 Op.general 51P2T
N1PTOC3 Str.general 51N1P
N1PTOC3 Op.general 51N1T
G1PTOC4 Str.general 51G1P
G1PTOC4 Op.general 51G1T
G2PTOC5 Str.general 51G2P
G2PTOC5 Op.general 51G2T
Q1PTOC6 Str.general 51Q1P
Q1PTOC6 Op.general 51Q1T
Q2PTOC7 Str.general 51Q2P
Q2PTOC7 Op.general 51Q2T
D87UPDIF1 Op.general 87U
D87UPDIF1 Op.PhsA 87U1
D87UPDIF1 Op.PhsB 87U2
D87UPDIF1 Op.PhsC 87U3
D87RPDIF2 Op.general 87R
D87RPDIF2 Op.PhsA 87R1
D87RPDIF2 Op.PhsB 87R2
D87RPDIF2 Op.PhsC 87R3
D87APDIF3 Op.general 87AT
REF1FPDIF4 Op.general REF1F
REF1PPDIF5 Op.general REF1P
HB24PHAR1 Str.general 2_4HBL 2_4HB1+2_4HB2+2_4HB3
Table F.10 Logical Device: PRO (Protection) (Sheet 2 of 3)
Logical Node Status Relay Word Bit Comment
