Analog Quantities
Analog Quantities
IBW2MN Winding 2 Current, B-phase, minimum
magnitude
A pri x x x
ICW2MN Winding 2 Current, C-phase, minimum
magnitude
A pri x x x
IGW2MN Winding 2 Current, residual, minimum
magnitude
A pri x x x
INMN Current, neutral, minimum magnitude A pri x x x
VABMX Voltage, A-to-B-phase, maximum magnitude V pri x x x
VBCMX Voltage, B-to-C-phase, maximum magnitude V pri x x x
VCAMX Voltage, C-to-A-phase, maximum magnitude V pri x x x
VAMX Voltage, A-phase-to-neutral, maximum
magnitude
V pri x x x
VBMX Voltage, B-phase-to-neutral, maximum
magnitude
V pri x x x
VCMX Voltage, C-phase-to-neutral, maximum
magnitude
V pri x x x
VABMN Voltage, A-to-B-phase, minimum magnitude V pri x x x
VBCMN Voltage, B-to-C-phase, minimum magnitude V pri x x x
VCAMN Voltage, C-to-A-phase, minimum magnitude V pri x x x
VAMN Voltage, A-phase-to-neutral, minimum
magnitude
V pri x x x
VBMN Voltage, B-phase-to-neutral, minimum
magnitude
V pri x x x
VCMN Voltage, C-phase-to-neutral, minimum
magnitude
V pri x x x
KVA3PMX Apparent power magnitude, 3-phase,
maximum
kVA pri x x x
KW3PMX Real power magnitude, 3-phase, maximum kW pri x x x
KVAR3PMX Reactive power magnitude, 3-phase, maximum kVAR pri x x x
KVA3PMN Apparent power magnitude, 3-phase,
minimum
kVA pri x x x
KW3PMN Real power magnitude, 3-phase, minimum kW pri x x x
KVAR3PMN Reactive power magnitude, 3-phase, minimum kVAR pri x x x
FREQMX Maximum frequency Hz x x x
FREQMN Minimum frequency Hz x x x
RTD1MX to
RTD12MX
RTD1 maximum to RTD12 maximum °C x x x
RTD1MN to
RTD12MN
RTD1 minimum to RTD12 minimum °C x x x
AI301MX to
AI304MX
Analog transducer input 301–304 maximum
a
EU x x x
AI301MN to
AI304MN
Analog transducer input 301–304 minimum
a
EU x x x
AI401MX to
AI404MX
Analog transducer input 401–404 maximum
a
EU x x x
Table K.1 Analog Quantities (Sheet 4 of 6)
Label Description Units
Display
Points
SELOGIC
Load
Profile
DNP
Fast
Meter
