Date Code 990430 Setting the SEL-351P Recloser Control 9-29
SEL-351P Manual Técnico
Row
Bit
Definition
Primary
Application
32PR Reverse directional control routed to phase
overcurrent elements (see Figures 4.19 and 4.21)
32QF Forward directional control routed to negative-
sequence overcurrent elements (see Figures 4.19 and
4.20)
32QR Reverse directional control routed to negative-
sequence overcurrent elements (see Figures 4.19 and
4.20)
32GF Forward directional control routed to residual ground
overcurrent elements (see Figures 4.4, 4.12, and
4.14)
32GR Reverse directional control routed to residual ground
overcurrent elements (see Figures 4.4, 4.12, and
4.14)
18 27A1 A-phase instantaneous undervoltage element A-phase
voltage below pickup setting 27P1P; see Figure 3.21)
Control
27B1 B-phase instantaneous undervoltage element
(B-phase voltage below pickup setting 27P1P; see
Figure 3.21)
27C1 C-phase instantaneous undervoltage element
(C-phase voltage below pickup setting 27P1P; see
Figure 3.21)
27A2 A-phase instantaneous undervoltage element
(A-phase voltage below pickup setting 27P2P; see
Figure 3.21)
27B2 B-phase instantaneous undervoltage element
(B-phase voltage below pickup setting 27P2P; see
Figure 3.21)
27C2 C-phase instantaneous undervoltage element
(C-phase voltage below pickup setting 27P2P; see
Figure 3.21)
59A1 A-phase instantaneous overvoltage element (A-phase
voltage above pickup setting 59P1P; see Figure 3.21)
59B1 B-phase instantaneous overvoltage element (B-phase
voltage above pickup setting 59P1P; see Figure 3.21)
19 59C1 C-phase instantaneous overvoltage element (C-phase
voltage above pickup setting 59P1P; see Figure 3.21)
59A2 A-phase instantaneous overvoltage element (A-phase
voltage above pickup setting 59P2P; see Figure 3.21)
