9-34 Setting the SEL-351P Recloser Control Date Code 990430
SEL-351P Manual Técnico
Row Bit Definition
Primary
Application
SV1T SEL OGIC Control Equation variable timer output
SV1T asserted (see Figure 7.23)
Control
SV2T SEL OGIC Control Equation variable timer output
SV2T asserted (see Figure 7.23)
SV3T SEL OGIC Control Equation variable timer output
SV3T asserted (see Figure 7.23)
SV4T SEL OGIC Control Equation variable timer output
SV4T asserted (see Figure 7.23)
29 SV5
SV6
SV7
SV8
SEL
OGIC Control Equation variable timer input SV5
asserted (see Figure 7.23)
SEL
OGIC Control Equation variable timer input SV6
asserted (see Figure 7.23)
SEL
OGIC Control Equation variable timer input SV7
asserted (see Figure 7.24)
SEL
OGIC Control Equation variable timer input SV8
asserted (see Figure 7.24)
Testing, Seal-in
functions, etc.
(see Figure 7.25)
SV5T SEL OGIC Control Equation variable timer output
SV5T asserted (see Figure 7.23)
Control
SV6T SEL OGIC Control Equation variable timer output
SV6T asserted (see Figure 7.23)
SV7T SEL OGIC Control Equation variable timer output
SV7T asserted (see Figure 7.24)
SV8T SEL OGIC Control Equation variable timer output
SV8T asserted (see Figure 7.24)
30 SV9
SV10
SV11
SV12
SEL
OGIC Control Equation variable timer input SV9
asserted (see Figure 7.24)
SEL
OGIC Control Equation variable timer input
SV10 asserted (see Figure 7.24)
SEL
OGIC Control Equation variable timer input
SV11 asserted (see Figure 7.24)
SEL
OGIC Control Equation variable timer input
SV12 asserted (see Figure 7.24)
Testing, Seal-in
functions, etc.
(see Figure 7.25)
SV9T SEL OGIC Control Equation variable timer output
SV9T asserted (see Figure 7.24)
Control
SV10T SEL OGIC Control Equation variable timer output
SV10T asserted (see Figure 7.24)
SV11T SEL OGIC Control Equation variable timer output
SV11T asserted (see Figure 7.24)
SV12T SEL OGIC Control Equation variable timer output
SV12T asserted (see Figure 7.24)
