Date Code 990430 Setting the SEL-351P Recloser Control 9-33
SEL-351P Manual Técnico
Row Bit Definition
Primary
Application
25 LB1
LB2
LB3
LB4
LB5
LB6
LB7
LB8
Local Bit 1 asserted (see Figure 7.3)
Local Bit 2 asserted (see Figure 7.3)
Local Bit 3 asserted (see Figure 7.3)
Local Bit 4 asserted (see Figure 7.3)
Local Bit 5 asserted (see Figure 7.3)
Local Bit 6 asserted (see Figure 7.3)
Local Bit 7 asserted (see Figure 7.3)
Local Bit 8 asserted (see Figure 7.3)
Control via front
panel – replacing
traditional panel-
mounted control
switches
26 RB1
RB2
RB3
RB4
RB5
RB6
RB7
RB8
Remote Bit 1 asserted (see Figure 7.9)
Remote Bit 2 asserted (see Figure 7.9)
Remote Bit 3 asserted (see Figure 7.9)
Remote Bit 4 asserted (see Figure 7.9)
Remote Bit 5 asserted (see Figure 7.9)
Remote Bit 6 asserted (see Figure 7.9)
Remote Bit 7 asserted (see Figure 7.9)
Remote Bit 8 asserted (see Figure 7.9)
Control via serial
port
27 LT1
LT2
LT3
LT4
LT5
LT6
LT7
LT8
Latch Bit 1 asserted (see Figure 7.11)
Latch Bit 2 asserted (see Figure 7.11)
Latch Bit 3 asserted (see Figure 7.11)
Latch Bit 4 asserted (see Figure 7.11)
Latch Bit 5 asserted (see Figure 7.11)
Latch Bit 6 asserted (see Figure 7.11)
Latch Bit 7 asserted (see Figure 7.11)
Latch Bit 8 asserted (see Figure 7.11)
Control –
replacing
traditional
latching relays
28 SV1 SEL OGIC Control Equation variable timer input SV1
asserted (see Figure 7.23)
Testing, Seal-in
functions, etc.
SV2 SEL OGIC Control Equation variable timer input SV2
asserted (see Figure 7.23)
(see Figure 7.25)
SV3 SEL OGIC Control Equation variable timer input SV3
asserted (see Figure 7.23)
SV4 SEL OGIC Control Equation variable timer input SV4
asserted (see Figure 7.23)
